Project:Smoothy UPDATES
Topic Started: Dec 27 2009, 10:53 AM (2,292 Views)
d.k.v
Member Avatar
laredo
[ *  *  *  * ]
Hi guys

id just like to give you a teaser on my new project.

Posted Image

I will Update as i go

This is the plan:
http://www.pirate4x4.com/forum/showthread.php?t=776208

Parts planed:

rc4wd 45t motor http://www.rc4wdstore.com/2/product_info.php?cPath=90&products_id=948
rc4wd T1 Disruptor Transfer Case http://www.rc4wdstore.com/2/product_info.php?cPath=37&products_id=505
rc4wd roklox http://www.rc4wdstore.com/2/product_info.php?manufacturers_id=14&products_id=813
Bartos chassis hemi motor http://bartoschassis.weebly.com/engine-shop.html
rc4wd Military wheels http://www.rc4wdstore.com/2/product_info.php?manufacturers_id=2&products_id=457
Custom styrene chassis
Custom Unimog suspention
wheely king axles
traxxas shocks (droop) traxxas slash rears all round
traxxas driveshafts
traxxas slash servos

and a totally scaled out body



Thanks
Matthew
Edited by d.k.v, Mar 15 2010, 10:21 AM.
PROJECT:SMOOTHY
Offline Profile Quote Post Goto Top

cxc
Member Avatar
JEEP U
[ *  *  *  *  *  *  *  *  * ]
cool, was wondering when you would start this build. :nice:
Offline Profile Quote Post Goto Top

d.k.v
Member Avatar
laredo
[ *  *  *  * ]
yer most of the body is sliced up...
one i get paid ill grab a chassis of big dodge and some styrene and fire this baby up.

will be just like yours firewall full floor. but i have dove tailed her aswell...
not as easy as it sounds

did you notice the is no windscreen tie down and bonnet latches
coz its Smooth
Edited by d.k.v, Dec 27 2009, 02:01 PM.
PROJECT:SMOOTHY
Offline Profile Quote Post Goto Top

cxc
Member Avatar
JEEP U
[ *  *  *  *  *  *  *  *  * ]
yep, i used some thick wire for the windshield supports and made the tie down from styrene.
Offline Profile Quote Post Goto Top

d.k.v
Member Avatar
laredo
[ *  *  *  * ]
do you know how wide the anthrax chassis is?
PROJECT:SMOOTHY
Offline Profile Quote Post Goto Top

jeffs396
Member Avatar
laredo
[ *  *  *  * ]
This is gonna be good! :popcorn:
1:1 Jeep...1974 J20 pickup
1:24/1:25 scale Jeeps...probably every one ever produced, and some scratchbuilt ones, too!


RESIN8 Posted Image RESIN8
Offline Profile Quote Post Goto Top

d.k.v
Member Avatar
laredo
[ *  *  *  * ]
jeffs396
Dec 28 2009, 04:29 AM
This is gonna be good! :popcorn:
thanks... i hope its good.

its part ogre(cxc build) and part my imagination
PROJECT:SMOOTHY
Offline Profile Quote Post Goto Top

Jeep 4x4
Member Avatar
A wrangler man

Looks interesting, and a good start! :nice:
It is no art to bought a jeep, its a art to live with it!
Offline Profile Quote Post Goto Top

d.k.v
Member Avatar
laredo
[ *  *  *  * ]
thanks im getting some styrene today to do the firewall and floor...
will do an update one iv done it
PROJECT:SMOOTHY
Offline Profile Quote Post Goto Top

d.k.v
Member Avatar
laredo
[ *  *  *  * ]
well time 4 an update aye.

my firewall and floor.
Posted Image

Posted Image

Tunnel will go in once i get the transfer case

Thanks for looking
PROJECT:SMOOTHY
Offline Profile Quote Post Goto Top

cxc
Member Avatar
JEEP U
[ *  *  *  *  *  *  *  *  * ]
i will get you measurements of the chassis after i get home from work today. :nice:
Offline Profile Quote Post Goto Top

Jeep 4x4
Member Avatar
A wrangler man

Thats some sharp styrene work on your firewall and floor! :nice:
It is no art to bought a jeep, its a art to live with it!
Offline Profile Quote Post Goto Top

d.k.v
Member Avatar
laredo
[ *  *  *  * ]
thanks guys.

the only styrene i could get was evergreen 'sidewalk' stiff. so one side its flat and the other is covered in 10mm squares. so im having to double it over. bit it dont matter because i need that thickness anyway
PROJECT:SMOOTHY
Offline Profile Quote Post Goto Top

d.k.v
Member Avatar
laredo
[ *  *  *  * ]
Well another update but only small
Bonnet mounts

From this:
Posted Image

To this:
Posted Image

Bonnet on mounts
Posted Image

Thanks For looking
PROJECT:SMOOTHY
Offline Profile Quote Post Goto Top

bigdodge88
Member Avatar
Owner of Toxic Fabrication
[ *  *  *  *  *  *  *  *  * ]
Nice body work so far bud. This one should be very nice. :nice: The chassis is about 3 1/4" wide, but I can make it as narrow/wide as you need.
Toxic Fabrication
Offline Profile Quote Post Goto Top
